Hydraulic Slitting Line

:2019-06-27 09:06:27 :Technology Information:21

Product
Name: Steel Slitting Line

Host
power: 7.5 * 2kw

Dimensions:
11000 * 3000 * 1700mm

Leveling
row number: 7 +8 row

Control
system PLC: imported high-precision PLC computer controller

Processing
sheet thickness: 2.0mm or less

Slitting
method: fully automatic

CNC strip
slitting line is completely designed and manufactured according to customer
requirements of an automatic cutting and slitting one of the shear, the device
components: raw material unwinding bracket (10T) → leveling → vertical shear → receive side Material → Pneumatic clamping device → Automatic winder (10T), according
to customer needs tailored cutting different number and thickness of the
slitting production line unit.



1. The
slitting line for sheet slitting production line, custom processing thickness
of 0.1-3.0mm

2. The
slitting line Machinable plate material: copper, stainless steel, cold plate,
silicon steel, tinplate and so on.

3. The
slitting line for the automatic slitting equipment, the entire line of
automatic processing, without artificial participation too much, saving
manpower and resources.

In the entire cutting process we must
always pay attention to the blade plane status, in the event of irregularities
to replace the new blade immediately, because the uneven blade will make the
blade shear resistance increases, the consequence is to make the gap between
the upper and lower blade increases , So that the metal strips have burrs on
both sides.



Pls
contact with me if you want it.
